The LS3 6.2L is the 430-hp standard engine in the Chevrolet Corvette and is a fantastic combination of high technology and uncompromising performance. Our LS3 crate engine comes complete, from the Corvette specific oil pan to the ignition system. It also includes the EFI intake manifold assembly with injectors and throttle body, water pump, balancer, 58X reluctor wheel.
Inside, the LS3 is filled with components designed for high performance and longevity. The aluminum block is filled with a sturdy reciprocating assembly that combines with L92-type rectangular-port heads to deliver a 10.7:1 compression ratio. A high-lift, hydraulic roller camshaft delivers a whopping 0.551-inch of lift on the 2.16-inch intake valves and 0.522-inch lift on the 1.59-inch exhaust valves, enhancing the LS3’s tremendous airflow and broad torque curve.
The Corvette oil pan doesn’t suit all installation applications. Use a vehicle-specific oil pan for original LS-powered vehicles or Chevrolet Performance’s Muscle Car Oil Pan Kit (P/N 19212593) for older versions.
TECH SPECS
Part Number: 19435098
Engine Type: LS-Series Gen-IV Small-Block V-8
Displacement (cu. in.): 376 (6.2L)
Bore x Stroke (in.): 4.065 x 3.622 (103.25 x 92 mm)
Block (P/N 12623967): Cast-aluminum with six-bolt, cross-bolted main caps
Crankshaft (P/N 12597569): Nodular iron
Connecting Rods (P/N 12607475): Powdered metal
Pistons (P/N 19207287): Hypereutectic aluminum
Camshaft Type (P/N 12603844): Hydraulic roller
Valve Lift (in.): .551 intake / .522 exhaust
Camshaft Duration (@.050 in.): 204° intake / 211° exhaust
Cylinder Heads (P/N 12629063): Aluminum L92-style port; “as cast” with 68-cc chambers
Valve Size (in.): 2.165 intake / 1.590 exhaust
Compression Ratio: 10.7:1
Rocker Arms (P/N 12569167 int): Investment-cast, roller trunnion
Rocker Arms (P/N 10214664 exh): Investment-cast, roller trunnion
Rocker Arm Ratio: 1.7:1
Recommended Fuel: 92 octane
Maximum Recommended rpm: 6600
Reluctor Wheel: 58X
Balanced: Internal
